Due to of all the clinical departments, the Department of stomatology (dentistry) has arguably the greatest pressure on infection control (infection control). When the high-speed turbine mobile phone and ultrasonic scaler are running,. They will mix the patient’s saliva and blood to produce a large number of aerosols and droplets. Which will fill the air; At the same time. The complex integrated treatment water pipes (DUWLs) inside the dental chair are a greenhouse for bacteria to grow and form biofilms.
Traditional disinfectants (such as alcohol. Hydrogen peroxide, glutaraldehyde, 84 disinfectant) often have the limitations of irritating. Corroding equipment, or not being able to continuously sterilize online when facing these special challenges in stomatology. The introduction of hypochlorous acid (HOCl) generator. With its unique physical and chemical characteristics. Accurately solves many pain points of oral sensing and control.
Hypochlorous acid generator parameters
| Model Name | Application of hypochlorous acid generator in stomatology SHT-SAEW-1000，2000，4000，6000，9000 |
|---|---|
| flow | 100L/H,200L/H，300L/H，500L/H，1000L/H（Flow can be customized） |
| Concentration | 10-500PPM（Adjustable） |
| Electrolyte | Salt（Nacl) Or Hydrochloric acid(HCL） |
| Hypochlorous acid PH | 5-6.5 |
| Sodium hydroxide PH | 10-13.5 |
| Voltage | 220V/50Hz，380V/50Hz，110V/60Hz |
| The proportion of hypochlorous acid in ACC | >98.50% |
| Softened water system | One on standby and one in use |
| Weight | 95kg，120kg,180kg，210kg |
| Dimensions of hypochlorous acid generator | Can be customized |
Advantages of hypochlorous acid generator in stomatology
1，End the biofilm, crisis in the Dental Chair Waterway (DUWLs)
Due to the water pipe of the dental comprehensive treatment table is thin in diameter. Slow in water flow, and often in the state of water shutdown. Therefore which can easily lead to the formation of stubborn Biofilm on the pipe wall. This is also the main culprit that leads to the total number of bacteria in the water used for diagnosis and treatment exceeding the standard and causing cross-infection.
- Efficient biofilm peeling: Hypochlorous acid is neutral or slightly acidic (pH 5.0-6.5). Due to its small molecular weight and no charge. Therefore it can easily penetrate the cell wall of bacteria and the extracellular polymer (EPS) matrix of biofilms to disintegrate biofilms from the inside.
- Low concentration online continuous disinfection: very low concentration (such as 2-5ppm) hypochlorous acid water is prepared on site through the hypochlorous acid generator. Which is directly connected to the independent water supply system of the dental chair. This “in-line” disinfection can ensure that the treatment water is up to or above drinking water standards without causing any irritation to the patient’s oral mucosa.
2.Hypochlorous acid effectively blocks the propagation of aerosols
At the same time aerosols from oral treatments can remain suspended in the air for hours and can easily cause cross-contamination in the office.
- Safe atomization, real-time disinfection: traditional disinfection needs to clear the field (such as ultraviolet). The hypochlorous acid is spray in the examination room by ultrasonic nebulizer. Which can be sterilized by air at the same time as medical operation. It quickly inactivates bacteria and viruses suspended in the air. Minimizing the risk of aerosol transmission.
- Comfortable medical experience: Hypochlorous acid has no pungent “Laisu water” or “high concentration of chlorine” smell in traditional hospitals. And is safe to breathe. This can effectively relieve the tension of patients, especially children. And enhance the brand image of the clinic.
3, mild and non-stimulating, perfectly suitable for oral mucosa and skin
- During dental treatment, patients’ oral mucosa is directly expose, and medical staff also need to wash their hands frequently.
>Preoperative oral rinse: before root canal treatment, tooth extraction or tooth cleaning, patients should rinse with low-concentration hypochlorous acid water for 30-60 seconds, which can significantly reduce the base of pathogenic bacteria in the oral cavity and reduce the pollution load of aerosol from the source. - Minimally invasive and intraoperative irrigation during implantation: Hypochlorous acid has excellent biocompatibility. Studies have show that it is non-toxic to fibroblasts and other normal tissue cells, and can be use for intraoperative wound irrigation with bactericidal and mild properties.
- Good news for frequent hand washing: Compared to alcohol quick-drying hand sanitizer, which can make skin skim, dry and cracked, hypochlorous acid hand sanitizer is extremely gentle on the skin and does not cause hand eczema over the long term.
4, low corrosion, protection of expensive dental precision instruments
There are many sophisticated dental equipment (such as precision mobile phones, root canal motors, oral endoscopes, etc.), which have high requirements for the corrosion of disinfectants. Strong alkaline chlorides such as 84 disinfectant will quickly damage the metal surface and rubber seal ring.
- Pre-treatment of precision instruments: replace dental handpieces, tooth extraction pliers, etc., can be soake or wiped with hypochlorous acid before entering high temperature autoclaving. Its slightly acidic to neutral characteristics to stainless steel, plastic, rubber corrosion is very low, can effectively extend the service life of expensive equipment.
- Wipe the surface of the comprehensive treatment table (dental chair) : At the same time quickly spray and wipe the surface of the dental chair leather, operating plate, strong and weak suction bracket and three guns to kill bacteria quickly and not destroy the leather and plastic materials.
For the pursuit of high-quality sensory control and modern management of oral clinic, hypochlorous acid generator is not only a disinfection equipment, but also a set of “air, waterway, surface, human body” four-in-one closed-loop sensory control solution. It is economical and efficient, making oral diagnosis and treatment safer and more secure.
