In an era where water sustainability is paramount, the efficient and safe treatment of reclaimed water is a critical component of responsible water management. Introducing the SHT-5000G Sodium Hypochlorite Generator, a state-of-the-art solution designed to elevate your water disinfection process. This powerful system is engineered for excellence, providing a reliable and cost-effective method for treating reclaimed water, ensuring it is safe for a multitude of reuse applications at the same time. The SHT-5000G is not just a piece of equipment; it is a commitment to a greener future, operational efficiency, and unparalleled safety.
1. The Critical Need for Advanced Reclaimed Water Disinfection
Reclaimed water, also known as recycled water, is a vital resource for communities and industries worldwide. From agricultural irrigation and industrial cooling to landscape maintenance and toilet flushing, its applications are vast and varied. However, to be utilized safely, reclaimed water must undergo a rigorous disinfection process to eliminate harmful pathogens, including bacteria, viruses, and other microorganisms.
Traditional disinfection methods, such as the transportation and storage of bulk sodium hypochlorite or chlorine gas, present numerous challenges. These include significant safety risks, logistical complexities, and escalating costs. The SHT-5000G Sodium Hypochlorite Generator directly addresses these issues by producing a powerful disinfectant on-site, on-demand, using only salt, water, and electricity.
2. Sodium hypochlorite generator parameter
| Product name | SHT-500G |
|---|---|
| Effective chlorine yield | 500g/H |
| Concentration | 6-8g/L（6000-8000ppm） |
| Power | 3KW |
| Salt consumption | 3.2KG/KG |
| Size | 2600*900*2000mm |
| Voltage | 380V/50hz |
3. Core Specifications and Advanced Features:
1. High-Efficiency Electrolytic Cell: At the heart of the SHT-5000G lies a technologically advanced electrolytic cell. Featuring pure titanium electrodes coated with a proprietary blend of precious metals, it guarantees optimal chlorine production and exceptional durability. The specialized coating protects against corrosion and ensures a long service life, significantly reducing the need for frequent replacements.
2. Intelligent PLC Control System: The SHT-5000G is equipped with a sophisticated Programmable Logic Controller (PLC) that automates the entire sodium hypochlorite generation process. This user-friendly interface allows for precise control over chlorine production, concentration levels, and also dosage rates. The system continuously monitors key operational parameters, ensuring consistent performance and immediate alerts for any potential issues.
3. Optimized Resource Consumption: Engineered for efficiency, the SHT-5000G minimizes the consumption of salt and electricity. Typically, the system consumes approximately 3.2 kilograms of salt and 4.5 kilowatts of electricity per kilogram of available chlorine produced. This translates to significant operational cost savings over the lifespan of the equipment.
4. Safe and Stable Disinfectant Production: The SHT-5000G produces a low-concentration sodium hypochlorite solution (typically 0.6-0.8%). This concentration is highly effective for disinfection yet is classified as a non-hazardous chemical, eliminating the risks associated with the handling and also storage of high-concentration chlorine products.
5. Durable and Corrosion-Resistant Construction: All components of the SHT-5000G that come into contact with the brine solution or sodium hypochlorite are constructed from high-quality, corrosion-resistant materials. This ensures the longevity of the system even in harsh operating environments.
4. Significant Cost Savings and Return on Investment
SHT-5000G is a financially astute investment that delivers substantial long-term savings.
1. Low-Cost Consumables: The system utilizes readily available and inexpensive consumables: salt, water, and electricity. This frees you from the volatile pricing and supply chain disruptions associated with commercially produced chlorine products.
2. Reduced Operational and Maintenance Costs: The automated nature of the SHT-5000G reduces the need for extensive operator supervision. Furthermore, the durable components and intelligent design minimize maintenance requirements and downtime.
3. On-Demand Production Eliminates Waste: The SHT-5000G produces sodium hypochlorite as needed, eliminating the chemical degradation and waste associated with the storage of bulk bleach.
Sodium hypochlorite generator catalog
5. Improved Water Aesthetics
In addition to its disinfection properties, the oxidizing power of sodium hypochlorite helps to improve the aesthetic quality of the reclaimed water. It can aid in the removal of unpleasant odors and the breakdown of some organic compounds that can cause discoloration.
SHT-5000G empowers your facility to consistently meet and exceed local and international water quality standards for reclaimed water. The precise control over dosing provided by the PLC system allows you to maintain the required residual chlorine levels to ensure the ongoing safety of the water in storage and also distribution systems.
5. A Trusted Partner in Over 30 Countries
FAQ
1. Is on-site generation safer than liquid chlorine?
Yes! No toxic gas storage or transport risks. The system produces only what you need at the same time.
2. What’s the maintenance requirement?
Minimal. Regular cell cleaning and also salt refills. Automated alerts simplify upkeep.
3. How to handle maintenance?
Automated alerts guide servicing.
Factory advantage
We have R&D centers, production centers, data centers and marketing centers. It is committe to providing technical support and innovative applications for improving public health security. Since its establishment, the company has obtained 12 invention patents and environmental management system certification. The company also has more than 30 test reports, covering surface and other different concentration detection projects. The series products sell well all over the country, and exported to such as Thailand, Malaysia, Cambodia, Brazil, South Africa, South America and other more than 20 countries and regions. The company has a perfect product sales and service system. To meet the needs of different customers with more professional services. So that to provide the best products and services for public health!
Customer feedback
