The Critical Mission of Water Treatment
Providing safe, clean drinking water is the most critical responsibility of a municipal water plant. Every day, communities depend on you. Therefore, disinfection is the final, essential barrier against waterborne pathogens.
SHT-10000G Sodium Hypochlorite Generator provides a simple, powerful alternative. We call it On-Site Generation, or OSG.
The concept is brilliant. Instead of buying your disinfectant, you create it. You produce your own sodium hypochlorite right at your facility.
How? The system uses only three simple ingredients:
Salt (common food-grade)
Water (softened water from your plant)
Electricity (to power the system)
The SHT-10000G passes an electrical current through a precise solution of saltwater (brine). This process, called electrolysis, safely and also efficiently converts the brine into a 0.8% sodium hypochlorite solution.
This 0.8% solution is just as powerful as traditional methods. But, it is vastly safer. It is stable. And, it costs significantly less to produce.
The Core Advantages: Why SHT-10000G is the Superior Choice
1. Guaranteed Disinfection Potency
Consistency is key to water safety.
Fresh On Demand: The SHT-10000G produces disinfectant as you need it. The solution moves from the generator to a storage tank, ready for dosing. You always use a fresh, full-strength solution.
No Degradation: Unlike bulk bleach, the 0.8% solution is highly stable. But, it is typically used within 24-48 hours anyway. You never have to guess the strength of your disinfectant.
Precise Dosing: Because the concentration is consistent (always 0.8%), your dosing pumps can be set with precision. This allows for a stable, predictable chlorine residual throughout your distribution system. Meanwhile, this consistency is crucial for regulatory compliance and public health. It also prevents over-dosing, which saves money and reduces the potential for disinfection byproducts (DBPs).
2. Smart, Automated Operation
SHT-10000G is designed for modern, efficient plants.
PLC Control: At its core is a robust Programmable Logic Controller (PLC). This is the “brain” of the system. It monitors all critical parameters in real-time.
User-Friendly HMI: A simple, intuitive Human-Machine Interface (HMI) touch screen displays system status, production rates, and also alarms. Operators can easily manage the system.
Self-Regulating: The generator automatically starts and stops based on the level in the disinfectant storage tank. It runs only when needed. This saves energy and optimizes the life of the components.
Advanced Alarms: The system protects itself. It includes alarms for low salt, low water flow, high temperature, rectifier faults, and also more. This ensures safe, reliable operation. Many models offer remote monitoring capabilities, allowing you to check system status from your central control room.
3. Durability and Reliability
A water plant runs 24/7/365. Your equipment must keep up.
Premium Electrode Technology: The heart of the SHT-10000G is the electrolytic cell. SHOOT uses high-quality titanium electrodes with a proprietary noble metal coating. This design ensures maximum conversion efficiency. It also guarantees a long service life, even under continuous operation.
Robust Build: All components—from the rectifier to the piping—are selected for their durability and chemical resistance. This system is built to last.
Smart Maintenance Features: The system includes automated processes, such as a soft water flush and an optional acid-washing cycle. These features keep the electrodes clean and maintain peak performance for years.
2. Sodium hypochlorite generator parameter
| Product name | SHT-10000G |
|---|---|
| Effective chlorine yield | 10000g/H |
| Concentration | 6-8g/L（6000-8000ppm） |
| Power | 60KW |
| Salt consumption | 3.2KG/KG |
| Size | 2600*900*2000mm |
| Voltage | 380V/50hz |
A Deeper Look: SHT-10000G Technology
The elegance of the SHOOT SHT-10000G is in its simplicity and power. The process is straightforward and transparent.
Step 1: Water Softening & Brine Creation
The process begins with your plant’s water. This water first passes through an industrial water softener. This is essential. Soft water prevents scale (calcium and magnesium) from building up on the electrodes, which ensures long life and also high efficiency.
Simultaneously, the soft water is used to dissolve food-grade salt in a brine tank, creating a saturated brine solution.
Step 2: Electrolysis
The system’s pumps precisely mix the saturated brine with more soft water, diluting it to the perfect concentration for electrolysis (around 3%). This solution then flows into the SHT-10000G electrolytic cell.
Inside the cell, the DC rectifier sends a controlled electrical current through the electrodes. This energy breaks apart the salt and also water molecules and reforms them.
(Salt + Water + Electricity→Sodium Hypochlorite + Hydrogen)
Step 3: Storage & Venting
The fresh 0.8% sodium hypochlorite (NaOCl) solution flows from the cell into a storage tank. This tank acts as a buffer, allowing the generator to run in efficient cycles.
Step 4: Dosing
From the storage tank, your existing (or new) chemical dosing pumps draw the 0.8% solution. They inject it into your water main, just as you would with bulk bleach. Meanwhile, the dosing is typically controlled by a flow meter or a chlorine residual analyzer, ensuring perfect disinfection.
The SHOOT Commitment: More Than Just a Product
When you choose the SHT-10000G, you are not just buying a piece of equipment. You are gaining a partner in water safety. SHOOT is committed to your success from day one.
Expert Consultation and Installation
Our team of engineers will work with you. We analyze your plant’s flow rates, your disinfection demands, and also your current costs. And, we help you select the perfect configuration. We provide full support during installation, ensuring the SHT-10000G integrates seamlessly into your existing process.
Comprehensive Training
The SHT-10000G is easy to use. However, we provide comprehensive training for your operators. We ensure your team is confident. They will understand the system’s operation, its smart controls, and also its simple maintenance procedures.
Long-Term Partnership and Support
Our relationship does not end at startup. SHOOT provides industry-leading after-sales support. We offer preventative maintenance programs. And, we stock genuine spare parts, including replacement electrodes. We are here to ensure your SHT-10000G provides safe, reliable disinfection for its entire long lifespan at the same time.
5. A Trusted Partner in Over 30 Countries
FAQ
1. Is on-site generation safer than liquid chlorine?
Yes! No toxic gas storage or transport risks. The system produces only what you need at the same time.
2. What’s the maintenance requirement?
Minimal. Regular cell cleaning and also salt refills. Automated alerts simplify upkeep.
3. How to handle maintenance?
Automated alerts guide servicing.
Factory advantage
We have R&D centers, production centers, data centers and marketing centers. It is committe to providing technical support and innovative applications for improving public health security. Since its establishment, the company has obtained 12 invention patents and environmental management system certification. The company also has more than 30 test reports, covering surface and other different concentration detection projects. The series products sell well all over the country, and exported to such as Thailand, Malaysia, Cambodia, Brazil, South Africa, South America and other more than 20 countries and regions. The company has a perfect product sales and service system. To meet the needs of different customers with more professional services. So that to provide the best products and services for public health!
