Reliable water treatment is the backbone of power plant efficiency. Biofouling in cooling water systems leads to heat exchanger inefficiency, pipe corrosion, and also unplanned shutdowns. At SHOOT, we provide the ultimate solution with our SHT-7000G Sodium Hypochlorite Generator.
We don’t just sell equipment. We deliver decades of global expertise. With a proven track record in over 30 countries, including Brazil, Zambia, and Turkey and so on, SHOOT is your trusted partner in high-capacity onsite chemical generation.
1. The Core Technology: Onsite Generation
Power plants require massive amounts of disinfectant. Relying on delivered liquid chlorine or commercial bleach is risky and also expensive.
How It Works
The SHT-7000G uses a simple yet sophisticated electrochemical process. It transforms salt, water, and also electricity into a high-purity sodium hypochlorite solution
By producing disinfectant right where you need it, you eliminate the hazards of transporting toxic chlorine gas. You also stabilize your operating costs by removing the volatility of chemical market prices.
Sodium hypochlorite generator parameter
| Product name | SHT-7000G |
|---|---|
| Effective chlorine yield | 7000-9000g/H |
| Concentration | 7-9g/L（7000-9000ppm） |
| Power | 45KW |
| Salt consumption | 3.2KG/KG |
| Size | 1900*900*2000mm |
| Voltage | 380V/50hz（Adjustable） |
3. The SHOOT Technical Advantage
What makes a SHOOT generator different from the rest? It comes down to the quality of the components and also the intelligence of the software.
Premium Electrode Technology
The heart of the SHT-7000G is the electrode assembly. We use pure titanium substrates coated with Ruthenium-Iridium (Ru-Ir) noble metal oxides.
Long Lifespan: Our electrodes last over 5 years under standard conditions.
High Catalytic Activity: This reduces voltage requirements and saves electricity.
Self-Cleaning: The optimized flow design reduces scale buildup.
Intelligent PLC Control
Modern power plants run on data. The SHT-7000G features a fully automated Siemens PLC control system.
One-Touch Start: Operators can start the entire sequence with a single button.
Remote Monitoring: Monitor your chlorine levels and system health from the central control room.
Safety Interlocks: The system automatically shuts down if it detects low water flow or high temperatures.
4. Unmatched Global Experience
Experience is the best teacher. SHOOT has successfully deployed water treatment solutions in diverse environments across the globe. We understand the unique challenges of different climates and local infrastructures.
Case Study: Brazil (Hydropower & Thermal)
In Brazil, humidity and remote locations make chemical delivery difficult. We installed multiple SHT units to treat cooling towers. Our systems withstood the tropical environment and also provided the plant with total chemical independence.
Case Study: Zambia (Mining Power Support)
In Zambia, we supported power facilities dedicated to copper mining. Reliability was the top priority. The SHT-7000G provided consistent disinfection despite fluctuating raw water quality.
Case Study: Turkey (Coastal Power Plants)
Turkey’s coastal plants often use seawater for cooling. We customized our electrolytic cells to handle high-salinity intake. This prevented marine growth (mussels and algae) from clogging critical intake pipes.
Our footprint spans 30+ countries. This global presence means we understand international shipping, local electrical standards, and also diverse environmental regulations.
Sodium hypochlorite generator catalog
5. Why Power Plants Prefer SHOOT
Power plant managers face intense pressure to reduce “Levelized Cost of Energy” (LCOE). The SHT-7000G helps achieve this in three ways:
Lower Operational Costs (OPEX)
Purchasing raw salt is significantly cheaper than purchasing concentrated bleach. Furthermore, the SHT-7000G is highly automated. You don’t need a dedicated team just to run the chlorination plant.
Enhanced Asset Protection
Biofouling causes “under-deposit corrosion.” This eats away at your expensive condenser tubes. By maintaining a precise, constant residual chlorine level, the SHT-7000G extends the life of your plant’s infrastructure.
Environmental Compliance
Moving away from chlorine gas improves your plant’s safety profile. It simplifies your “Risk Management Plan” (RMP) and also makes it easier to pass environmental audits.
A Trusted Partner in Over 30 Countries
Our global success is not an accident. It is the result of a relentless focus on quality, performance, and also customer support. The SHT-7000G has been successfully deployed in hospitals, water treatment plants, and industrial facilities across Asia, Africa, Europe, and also the Americas.
This international footprint demonstrates the system’s versatility and also its ability to meet diverse international standards. When you choose the SHT-7000G, you are choosing a technology that is tested, proven, and trusted by professionals around the world.
FAQ
1. Is on-site generation safer than liquid chlorine?
Yes! No toxic gas storage or transport risks. The system produces only what you need at the same time.
2. What’s the maintenance requirement?
Minimal. Regular cell cleaning and also salt refills. Automated alerts simplify upkeep.
3. How to handle maintenance?
Automated alerts guide servicing.
Factory advantage
We have R&D centers, production centers, data centers and marketing centers. It is committe to providing technical support and innovative applications for improving public health security. Since its establishment, the company has obtained 12 invention patents and environmental management system certification. The company also has more than 30 test reports, covering surface and other different concentration detection projects. The series products sell well all over the country, and exported to such as Thailand, Malaysia, Cambodia, Brazil, South Africa, South America and other more than 20 countries and regions. The company has a perfect product sales and service system. To meet the needs of different customers with more professional services. So that to provide the best products and services for public health!
