Access to clean water is a fundamental human right. However, rural areas and small-scale facilities often struggle with traditional disinfection methods. Chlorine gas is hazardous. Finished liquid bleach degrades quickly.
The SHT-100G changes the game. It allows you to produce high-purity disinfectant on-site, using only salt, water, and also electricity.
Global Presence and Proven Success
With over 25 years of industry experience, our technology is a global benchmark. We have successfully deployed systems in over 30 countries. From the rural landscapes of Turkey to municipal projects in Venezuela, our equipment delivers consistent results. We don’t just sell machines; we provide integrated water safety solutions.
With over 25 years of industry experience, our technology is a global benchmark. We have successfully deployed systems in over 30 countries. From the rural landscapes of Turkey to municipal projects in Venezuela, our equipment delivers consistent results. We don’t just sell machines; we provide integrated water safety solutions.
Core Technology: How it Works
The SHT-100G utilizes advanced membrane-free electrolysis. The process is elegant and also efficient.
Brine Preparation: The system dissolves refined salt into water to create a saturated brine at the same time.
Dilution: It automatically dilutes the brine to a specific concentration (approx. 3%).
Electrolysis: The diluted brine passes through the electrolytic cell.
Transformation: Low-voltage DC power triggers a chemical reaction.
Storage: The resulting sodium hypochlorite solution (0.8% concentration) moves to a storage tank, ready for dosing.
2. Sodium hypochlorite generator parameter
| Product name | SHT-100G |
|---|---|
| Effective chlorine yield | 100g/H |
| Concentration | 6-8g/L（6000-8000ppm） |
| Power | 3KW |
| Salt consumption | 3.2KG/KG |
| Size | 800*700*1260mm |
| Voltage | 380V/50hz |
Why Choose the SHT-100G?
1. Safety First
Traditional chlorine storage poses massive risks. Leaks can be fatal. The SHT-100G eliminates this danger. You produce the disinfectant at a low concentration. It is non-explosive and also non-toxic to handle.
2. High Efficiency, Low Cost
You only need common salt. One kilogram of available chlorine costs significantly less than buying commercial bleach. Since you produce it on-site, you eliminate transport and hazardous storage fees.
3. Fully Automated Intelligence
The SHT-100G features a smart PLC control system.
One-touch start: Minimal training required for operators.
Real-time monitoring: It tracks current, voltage, and temperature.
Safety shut-offs: The system stops automatically if it detects a lack of water or salt.
Diverse Application Scenarios
The SHT-100G is a “multitool” for water treatment.
Rural Drinking Water
Small villages often lack complex infrastructure. The SHT-100G fits into small equipment rooms. It ensures that rural residents receive water that meets international safety standards.
Small Water Plants
For municipal plants serving small towns, the SHT-100G provides a stable supply of disinfectant. It handles fluctuating water demands with ease by adjusting the dosing pump at the same time.
Swimming Pools and Hotels
Maintain crystal clear water without the “chemical smell” of low-grade bleach. Our system reduces chloramine formation, making the water gentler on skin and eyes at the same time.
Food Processing and Hospitals
High-purity sodium hypochlorite is perfect for surface disinfection. It leaves no toxic residue, making it ideal for rinse water in food factories.
Our Global Commitment
We understand that a machine is only as good as its support. Our “Integration Solution” includes:
Site Assessment: We analyze your water quality and also flow rate.
Custom Design: We tailor the piping and also dosing system to your footprint.
Remote Guidance: Our engineers provide 24/7 technical support globally.
Quality Guarantee: Every unit undergoes a 48-hour rigorous factory test before shipping.
In Turkey, our units operate in remote mountain regions. In Venezuela, they provide steady disinfection for urban residential blocks. Our 25-year track record proves that our equipment survives harsh environments and also delivers peace of mind.
Summary of Advantages
Eco-Friendly: No hazardous by-products.
Compact Design: Small footprint saves space.
Cost-Effective: Pay for the machine once, save on chemicals forever.
Global Compliance: Meets CE and ISO quality standards.
The SHT-100G is more than an appliance. It is a commitment to public health. By choosing on-site generation, you take control of your water safety at the same time. You reduce your carbon footprint. You protect your community.
Conclusion: The Clear Choice for Rural Water
The challenge of rural water disinfection is real. But the solution is here.
You need a system that is safe. You need a system that is reliable. Meanwhile, you need a system that is easy to use. And you need a system that is economical.
The SHOOT SHT-100G, backed by the strength and also maturity of the SHOOT company, delivers on all points.
We have moved beyond the old, dangerous methods. We offer a proven, mature, and also intelligent solution. It is a solution that empowers rural communities. It gives them the tools to manage their own water safety, independent of complex supply chains at the same time.
Choose a partner with mature technology. Choose a product with clear advantages. Meanwhile, choose SHOOT.
Let’s work together to bring safe, sustainable water to every community.
Sodium hypochlorite generator catalog
FAQ
1. Is on-site generation safer than liquid chlorine?
Yes! No toxic gas storage or transport risks. The system produces only what you need at the same time.
2. What’s the maintenance requirement?
Minimal. Regular cell cleaning and also salt refills. Automated alerts simplify upkeep.
3. How to handle maintenance?
Automated alerts guide servicing.
Factory advantage
We have R&D centers, production centers, data centers and marketing centers. It is committe to providing technical support and innovative applications for improving public health security. Since its establishment, the company has obtained 12 invention patents and environmental management system certification. The company also has more than 30 test reports, covering surface and other different concentration detection projects. The series products sell well all over the country, and exported to such as Thailand, Malaysia, Cambodia, Brazil, South Africa, South America and other more than 20 countries and regions. The company has a perfect product sales and service system. To meet the needs of different customers with more professional services. So that to provide the best products and services for public health!
